New FOXBORO IGP10-V22D1F PRESSURE TRANSMITTER

The Foxboro IGP10 is a direct-connected gauge pressure transmitter in the I/A Series instrument family, measuring liquid and gas pressure through a silicon strain-gauge sensor. The -V electronics fitted to this unit make it the low-power version of the line: it runs from a 9 to 15.5 V dc supply, draws no more than 3 mA, and delivers the measurement as a 1 to 5 V dc analog signal — a sensible fit where supply power is limited, such as remote or battery-fed monitoring points. An LCD indicator with pushbuttons is standard, so zero, span, and configuration can be handled right at the transmitter.

This listing is model IGP10-V22D1F. Span limit code D covers calibrated spans of 10 to 300 psi within a 0 to 300 psi range, protected by a 450 psi maximum overrange and a 1,200 psi proof pressure rating. Structure code 22 pairs a 316L stainless steel process connection (1/2 NPT external, 1/4 NPT internal) with a 316L stainless steel sensor diaphragm and silicone fill, and the epoxy-finished aluminum housing carries 1/2 NPT conduit entries and FM electrical-safety approvals. The transmitter is US-made and comes new and factory sealed.

Condition: New, sealed, as listed. The photographs are of the actual unit you'll receive, covered by our warranty.
