New · Sealed In stock
NEW EMERSON DELTAV KL3004X1-BA1 DO 24 VDC Isolated 12P4633X052 REV G – QTY stock
SKU: KL3004X1-BA1 · Emerson
$199
Ships with actual-unit photos and the Network Orbitz warranty.
About this item
The Emerson KL3004X1-BA1 is the DO 24 VDC Isolated CHARM for DeltaV Electronic Marshalling: one galvanically isolated discrete output channel rated 1 A continuous, with a 4 A current-limiting circuit and thermal shutoff. It clips into a CHARM terminal block on a baseplate alongside up to 95 other channels per CHARM I/O Card.
Condition: New, factory sealed, as listed. The photographs are of the actual unit you'll receive, covered by our warranty.
Emerson DeltaV I/O card, new in manufacturer packaging with the ATEX instruction bag shown.
Please note a discrepancy in the listing itself: the title describes the DO 24 VDC Isolated card (KL3004X1-BA1, assembly 12P4633X052 Rev G), but the photographed bag label reads assembly 12P4629X042 (serial P133472789), which belongs to the AO 4-20 mA HART card family. If the exact card type matters for your system, contact us before ordering and we will confirm the part number of the unit that ships.
Specifications
| Platform | DeltaV Electronic Marshalling (single-channel CHARM I/O) |
|---|---|
| CHARM type (per title) | Discrete output, 24 VDC isolated (Emerson ordering model SE4302T02) |
| Output range | 4 to 32 VDC |
| Output rating | 1.0 A continuous; 2 A inrush for <100 ms |
| Isolation | Galvanically isolated output, factory tested to 1000 VDC |
| Protection | 4 A current-limiting circuit with thermal shutoff; field wiring disconnect |
| Assembly number | 12P4633X052 Rev G (per title; see photographed-unit note) |
| Type | DELTAV |
|---|---|
| MPN | KL3004X1-BA1 |
| Brand | Emerson |
| Warranty | Network Orbitz warranty from delivery: repair, replacement, or refund on functional defects. Sealed units may also carry the manufacturer warranty. |
|---|---|
| Returns | Start an RMA with your order number — we respond with a number and prepaid return instructions. |
| Shipping | Tracked, insured carriers (DHL, FedEx, UPS) to 30+ countries. Freight crating for heavy items. |
| Duties & customs | International duties and taxes are billed by your local customs authority — we're happy to advise on documentation before you order. |
