NEW Emerson DeltaV 12P4632X122 KL3003X1-BA1 DI 24 VDC Dry Contact Rev P
SKU: 12P4632X122 · Emerson
$295
Ships with actual-unit photos and the Network Orbitz warranty.
About this item
The Emerson KL3003X1-BA1 is a single-channel discrete input CHARM for DeltaV Electronic Marshalling. Each CHARM characterizes one 24 VDC dry-contact signal and clips into a terminal block on a CHARM baseplate, so input types can be assigned channel by channel instead of card by card. The channel can run as a discrete input or a pulse count input.
This listing is for one DI 24 VDC Dry Contact CHARM, Emerson assembly 12P4632X122 Rev P as shown in the title, new and factory sealed.
Condition: New, factory sealed, as listed. The photographs are of the actual unit you'll receive, covered by our warranty.
Specifications
| Platform | DeltaV Electronic Marshalling (single-channel CHARM I/O) |
|---|---|
| CHARM type | Discrete input, 24 VDC dry contact (Emerson ordering model SE4301T02) |
| Detection levels | On: >2.25 mA; Off: <1.75 mA |
| Wetting voltage | 22.5 V ±5%, current limited to 12.5 mA nominal |
| Channel types | Discrete input or pulse count (pulse train 0.1 Hz to 10 kHz) |
| Protection | 12.5 mA current-limiting circuit; field wiring disconnect |
| Operating temperature | -40 to +70 °C |
| Assembly number | 12P4632X122 Rev P (as listed) |
| Brand | Emerson, Fisher-Rosemount |
|---|---|
| Model | KL3003X1-BA1 |
| MPN | 12P4632X122 |
| Country of Origin | United States |
| Warranty | Network Orbitz warranty from delivery: repair, replacement, or refund on functional defects. Sealed units may also carry the manufacturer warranty. |
|---|---|
| Returns | Start an RMA with your order number — we respond with a number and prepaid return instructions. |
| Shipping | Tracked, insured carriers (DHL, FedEx, UPS) to 30+ countries. Freight crating for heavy items. |
| Duties & customs | International duties and taxes are billed by your local customs authority — we're happy to advise on documentation before you order. |
