Allen Bradley 25B-D2P3N104 /A PowerFlex 525 AC Drive 480V/2.3A/1.0HP FRN 5.001

Stock photos for reference, followed by photos of the actual unit that ships.

Warranty included Ships to 30+ countries

New · Open Box Out of stock

Allen Bradley 25B-D2P3N104 /A PowerFlex 525 AC Drive 480V/2.3A/1.0HP FRN 5.001

SKU: 25B-D2P3N104 · Allen-Bradley

$245

Volume pricing available · Configuration changes welcome

Request a quote

Need a different configuration or quantity? Call toll-free +1 (877) 567-2489 or ask for options.

Ships with actual-unit photos and the Network Orbitz warranty.

About this item

The Allen-Bradley PowerFlex 525 is the fuller-featured member of the 520-series compact drives, pairing a modular power/control design with embedded EtherNet/IP and Safe Torque Off as standard — a fit for conveyors, pumps, fans and standalone machines that need networked speed control in a small panel footprint. Catalog 25B-D2P3N104 is the 0.75 kW / 1 HP, 2.3 A rating fed from 380-480 V three-phase, in the frame A, IP20 open-type package.

This listing is a Series A drive with firmware 5.001 on its rating label. It is new stock, not in its original manufacturer's box, and may show minor cosmetic scratches from handling, visible in the photographs.

Condition: New, not in original manufacturer's box, as listed. The photographs are of the actual item you'll receive, covered by our warranty.

Specifications

Product linePowerFlex 525 (Bulletin 25B, 520-series)
Output current2.3 A — 0.75 kW / 1 HP (normal and heavy duty)
Input380-480V AC, 3-phase, 47-63 Hz
Output frequency0-500 Hz programmable
Embedded commsEtherNet/IP port + RS-485 (DSI)
SafetySafe Torque Off (SIL2 / PLd, Cat. 3)
Form factorFrame A, IP20 NEMA/Open Type, no internal filter
SeriesA
FRN5.001
MPN25B-D2P3N104
BrandAllen-Bradley
