Allen Bradley 1769-OF8C /A CompactLogix 8 Ch Analog Output Current Module FW 2.2
SKU: 1769-OF8C · Allen-Bradley
$999
Ships with actual-unit photos and the Network Orbitz warranty.
About this item
The Allen-Bradley 1769-OF8C is a Compact I/O 8-channel analog current output module for CompactLogix and MicroLogix 1500 systems: eight single-ended 0-20 mA / 4-20 mA outputs at 16-bit resolution, made to drive control valves, actuators and other current-loop devices with ±0.35% full-scale accuracy into loads up to 500 Ω.
This listing is a Series A module with firmware 2.2.
Condition: Used, tested, as listed, covered by our warranty.
Used, tested unit: the reference photo shows the module face (OUTPUT · ANALOG, channels 0–7); the remaining photos show the exact unit that ships — its catalog label, open terminal door and side profile.
Specifications
| Outputs | 8 single-ended analog current channels |
|---|---|
| Ranges | 0-20 mA / 4-20 mA (full scale to 21 mA) |
| Resolution | 16-bit, 0.323 µA/bit |
| Accuracy | ±0.35% full scale at 25 °C |
| Load range | 0-500 Ω |
| Isolation | 500V AC / 710V DC (1 min), outputs to bus |
| Firmware | 2.2 |
| Brand | Allen-Bradley |
|---|---|
| MPN | 1769-OF8C |
